8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00604
208 L Firmware 03.00 - DMS EN 5.0 - 07/2009
C00604
C00606
C00620
Parameter | Name:
C00604 | Resp. to device overload (Ixt)
Data type: UNSIGNED_8
Index: 23971
d
= 5DA3
h
Response if the adjustable device utilisation threshold (C00123) is reached.
• The current device utilisation is displayed in C00064
.
Selection list (Lenze setting printed in bold)
0 No Reaction
1Fault
4 WarningLocked
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00606 | Resp. to motor overload (I²xt)
Data type: UNSIGNED_8
Index: 23969
d
= 5DA1
h
Response if the adjustable motor overload threshold (C00120) is reached.
• The current thermal motor load is displayed in C00066
.
Selection list (Lenze setting printed in bold)
0 No Reaction
1Fault
4 WarningLocked
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00620 | 16-bit system connection
Data type: UNSIGNED_16
Index: 23955
d
= 5D93
h
Connection parameters: 16-bit inputs
• Selection of the 16-bit output signals for connection with the 16-bit input signals.
• The selection list contains all 16-bit output signals which can be assigned to the 16-bit inputs mapped by the
subcodes.
Selection list Info
0Not connected
1 C_nPos100_a(100.0%)
2 C_nNeg100_a(-100.0%)
3 C_nPos199_9_a(199.9%)
4 C_nNeg199_9_a(-199.9%)
5 C_w65535
6C_wDriveCtrl
10 AIn1_Out
20 nPar1_a
21 nPar2_a
22 nPar3_a
23 nPar4_a
24 LS_Keypad_nTorqueMotLim_a
25 LS_Keypad_nTorqueGenLim_a
26 LS_Keypad_nMainSetValue_a
50 LA_NCTRL_nMotorFreqAct_a
51 LA_NCTRL_nOutputSpeedCtrl_a
52 LA_NCtrl_nMotorSpeedAct_a
53 LA_NCtrl_nMotor Voltage_a
54 LA_NCtrl_nDCVoltage_a
55 LA_NCtrl_nMotorCurrent_a
