Leopard Catamarans 40 - Page 178

170 | 2-35 Drawings170 | 2-35 Drawings
500
2240
975
1950 2325
7670
965
FLOOR LEVEL
Traili ede o Keel
Cocks
Fwd Cai Blkead Positio
Eie Roo Blkead Positio
At Cock der keel st e at least 500 wd o traili ede
Cock essel o cradle
NOTES . ON LAND, VESSEL MAY BE SUORTED ON ITS KEEL, AS LONG AS THE KEEL
TRAILING EDGE
IS KET UNLOADED (AS SHOWN)
. CRADLES ARE REUIRED TO REVENT OVERBALANCING (AS SHOWN) . ROFESSIONAL RIGGERS TO BE USED WHEN OSITIONING BOAT ON LAND. THIS DRAWING SHOULD ONLY BE USED AS A GUIDE. . VESSEL MAY DRY OUT ON ITS KEELS ON A SANDY BOTTOM, AS LONG AS THE KEEL IS EVENLY SUORTED ALONG ITS LENGTH . THIS DIAGRAM AND INSTRUCTION IS INTENDED AS ADVICE AND INFORMATION ONLY AND ROBERTSON  CAINE (TY) LTD, ITS MEMBERS ANDOR ITS STAFF SHALL NOT BE LIABLE FOR ANY DAMAGE TO THE VESSEL ANDOR OTHER LOSS ARISING FROM RELIANCE THEREON OR OTHERWISE.
REV
DATE
SIGN
MODIFICATION
EF.BOAT
A
20141104

FIRST ISSUE
B1001
B1 TCF esse Support on Land
 24, 2014
HL
A3
SHEET 1 OF 1
SCALE:1:45
DWG NO.
TITLE: REVISION:
MATERIAL:
DATE
SIGN
NAME
Q.A PROD: APPV'D: DRAWN: MODEL:
HL
Sep 25, 2014
P.O. Box 43341 Woodstock 7915 Tel: +27-21-4485666 Fax: +27-21-4485741
B1 TCF-00
ROBERTSON & CAINE (Pty) Ltd
A
Notes:
WEIGHT:
