Leopard Catamarans 40 - Digital Radar; 2-25.4 Digital Radar

2-25 Optional Extras | 95
1. Enginemustbeoffandcooltotouch.
2. WARNINGDonotleavetheself-
ventingdrainopenfortoolongasit
coulddraintheentirelterandpossibly
theentirefuelsystem
3. Withanappropriatecollectionpanin
placeopenself-ventingdrainonthe
bottomofsee-throughbowlandallow
waterandothercontaminantstodrain
intothecollectionpan.
4. Closeself-ventingdrainatrst
indicationofcleanfuel.Tightenby
hand only - do not use tools
5. Follow‘PrimingInstructions.
Element Replacement:
Thefrequencyofelementreplacementis
determinedbythecontaminationlevelof
thefuel.Replacetheelementsevery
10,000miles,every500hours,every
otheroilchange,ifpowerlossisnoticed,
orannually,whicheveroccursrst.
1. Enginemustbeoffandcooltotouch.
2. Remove T-handle and lid.
3. Remove the element by holding the
bailhandlesandopenslowlypulling
upwardwithatwistingmotion.
4. ReplacelidgasketandT-handleO-ring
withnewassembly.(suppliedwithnew
element).Lubricatebothsealswith
cleanfuelormotoroil
5. Install new element.
6. Follow‘PrimingInstructions.
2-25.4 Digital Radar
WARNING
RADIOFREQUENCYRADIATION
HAZARD
Theradarantennaemitselectromagnetic
energyatmicrowaveradiofrequencies
whichcanbeharmful,particularlytoyour
eyes.DONOTlookattheantennaat
closerange.ItisimportantthattheRadar
isturnedoffwheneverpersonnelare
requiredtocomeclosetothescanner
assembly.
Themaximumpowerdensitylevelwhich
isconsideredsafeforgeneralpublic
exposureis10W/m².Thedistancefrom
thescannerwithinwhichtheselevelsmay
beexceededis1.0metres.
Scanner setup
Afteryouhaveinstalledyourradar,and
beforeyougotosea,itisimportantto
checktheinstallation.Youcanthensetup
theradarsystem,alignthescannerand
checkthesystemtiming.
Setup,alignmentandtimingchecksare
performedfromtheradarsystemdisplay
unit.Theproceduresareoutlinedonthis
page;fulldetailsareavailableinthe
relevantdisplayunitOwner’sHandbook.
Youshouldreadthisandfamiliarize
yourselfwiththeoperationoftheradar.
EMCconformance
Alwayschecktheinstallationbeforegoing
toseatomakesurethatitisnotaffected
byradiotransmissions,enginestarting,
etc.
Thiswarningisdirectlyextractedfromthe
RaymarineDigitalRadomeScannerUser
Guide.
RaydomeonMastBracket
