2-17 Steering System Operation | 67
2-17.1 EMERGENCY STEERING
DANGER
IN THE EVENT OF THE STEERING
SYSTEM FAILING, AN EMERGENCY
TILLER MAY BE FITTED ON TO THE
HEAD OF EITHER THE PORT OR
STARBOARD RUDDER STOCK. THIS
CANBEACCESSEDTHROUGHADECK
PLATETHATISSITUATEDONTHEPORT
ANDSTARBOARDTRANSOMSTEPS.IN
HEAVYSEASABLOCKANDTACKLEMAY
BE RIGGED ON TO THE EMERGENCY
TILLER TO AID STEERING.
Theemergencytillerislocated
clippedtotheinsideoftheliferaftlocker
lid at the transom
Theemergencytillerdeckplate
islocatedonthelowerstepof
the transom on both sides
Theemergencytillerdeckplate
withcoverremoved
Theemergencytiller
deckplatewithcovertted
Theemergencytillertted
readyforuse
