3 Holding the card by its sides, align the plastic pins on the card with the holes on the system board.
2
1
1 Plastic pins
2 Metal pins
4 Push the card firmly into place.
Notes:
The entire length of the connector on the card must touch and be flush against the system board.
Be careful not to damage the connectors.
Installing an Internal Solutions Port
The system board supports one optional Lexmark Internal Solutions Port (ISP).
Note: This task requires a flathead screwdriver.
CAUTION—SHOCK HAZARD: If you are accessing the system board or installing optional hardware or memory
devices sometime after setting up the printer, then turn the printer off, and unplug the power cord from the
wall outlet before continuing. If you have any other devices attached to the printer, then turn them off as well,
and unplug any cables going into the printer.
Additional printer setup 28

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark C950 Series and is the answer not in the manual?

Lexmark C950 Series Specifications

General IconGeneral
Print TechnologyColor Laser
Print Resolution1200 x 1200 dpi
Monthly Duty CycleUp to 300, 000 pages
Standard Output Capacity500 sheets
Duplex PrintingYes
Processor Speed1.2 GHz
Operating System CompatibilityWindows, Mac OS, Linux
Print SpeedUp to 50 ppm
Memory1024 MB (Upgradable to 2048 MB)
ConnectivityUSB, Ethernet
Media Sizes SupportedA3, A4, A5, Executive, Folio, Legal, Letter, Statement, Universal
Standard Input Capacity620 sheets
Max Paper Capacity5, 140 sheets
