4511-xxx
2-76 Service Manual
89 xx 03 x1
x2 x3
The exit sensor did not detect the trailing
edge of the media.
(x1=bit7:filtered exit sensor state;
bits 6–0:H1(time exit sensor covered),
x2=suspect gap measurement at input
sensor, x3=Low(time exit sensor
covered).)
• This failure can be caused by a broken
fuser exit sensor flag.
• This may also be caused by erratic
operation of exit sensor flag or exit
sensor or a defective piece of media.
202
89 xx 04 x1
x2 00
The exit sensor never actuated from the
sheet going through the fuser before the
next page entering the sensor.
(x1=media size, x2=GeneralFlags1.)
202
89 xx 0D 00
x2 x3
The fuser exit sensor bounced.
(x2 + x3=paper path location.)
Check the exit sensor for correct
operation. Check the sensor cable to J16
on the controller card. Also, the controller
card may be failing.
202
8A 39 x1 x2
x3 x4
Printhead driver IR: LE at image point
based on lock assumption that proved to
be wrong.
(x1=printead type, x2=1 if lock,
x3, x4=time since printhead start.)
Sub error codes (continued)
First 6 bytes sub
error code data
(xx can be any
value)
Explanation
Possible
error
message
