4511-xxx
Diagnostics—E340 and E342n
2-77
8D 00 00 00
00 00
The fuser exit sensor was never activated
by the leading edge of the media fed
through the printer.
• This error can be displayed after a 201
paper jam.
• This can be caused by a defective fuser
exit sensor assembly.
Note: Enter the diagnostic tests menu,
select Base Sensor Tests, select
Output Sensor Test and check the
fuser exit sensor for correct operation.
If the test fails, check the cable
connection to J17 on the controller
card.
201
8D 00 01 00
00 00
User pressed Go or Continue after an
8D xx 00 jam, but never opened the
front access cover. Need to open cover
and clear any media under cartridge
before continuing.
201
8E xx 00 x1
x2 x3
Sheet being duplexed never made it to the
input sensor.
(x1=source, x2+x3=time since pick)
8E xx 08 00
00 00
Page in output hopper flushed; page
ahead of it in the paper path never made it
out of the tray.
8E xx 09 x1 The second pick from Tray 1 failed when
other sheets were committed to the paper
path.
(x1=media source)
250
8E x1 10 x2
x3 x4
Received lots of dc feed interrupts before
losing them. Tray 2 motor stall.
(x1=DCFeedMSCounter,
x2=IntegralPWM,
x3+x4=DCFeedRQCount.)
Sub error codes (continued)
First 6 bytes sub
error code data
(xx can be any
value)
Explanation
Possible
error
message
