4511-xxx
Repair information
4-7
7. Remove the screws (D) holding the button card assembly to the front
access cover.
8. Unlatch the LCD display (right and left sides).
9. Carefully pull the LCD assembly away from the front access cover.
10. Disconnect the LCD panel and controller card.
11. Open the front access cover, and position the cable outside the cover.
12. Place thumbs on the inside of the respective hinge.
D
