Lexmark E240n

4511-xxx
Repair information
4-23
4. Align the flat portion on the right end of the shaft with the opening of
the bearing support, and lift the right end of the shaft through the
support.
5. Swing the shaft away from the printer to expose the sensor flag.
6. Remove the two screws (B) securing the fuser.
B
