Lexmark E240n

4511-xxx
4-24 Service Manual
7. Slide the fuser out just enough to access the screw holding the sensor.
8. Unsnap the sensor from the bracket.
9. Observe the orientation of the flag (C) and spring (D) before replacing
units.
10. Remove the sensor and its attached cable.
C
D
