Lexmark MS310 Series - Nameplate Removal; Control Panel Assembly Removal

Nameplate removal
1 Open the front door.
2 Remove five screws (A) securing the nameplate.
A
Control panel assembly removal
1 Remove the right cover. See “Right cover removal” on page 160.
2 Remove the nameplate. See “Nameplate removal” on page 174.
3 Remove the bezel. See “Bezel removal” on page 173.
4514-220, -230
Repair information
174
