Lexmark MS310 Series Service Manual

Printer hardware errors
1xx error messages
Error code Description Action
111.00 Pel clock check failed. Go to “111.xx LSU service check” on page 93.
111.01 Downlevel ASIC detected.
111.31 Printhead never delivered HSYNCs.
111.32 Printhead lost HSYNCs.
111.40 Wrong printhead installed
111.50 Open-loop printhead error, open-loop sweep state.
111.51
111.52 Open-loop printhead error, check prelim amp state.
111.53 Open-loop printhead error, enable amp Kp state.
111.54 Closed-loop printhead error, amp Kp failed to
converge.
111.55 Closed-loop printhead error while waiting for amp Kp
to converge.
111.56 Closed-loop printhead error, amp Ki failed to
converge.
111.57 Closed-loop printhead error while waiting for amp Ki
to converge.
111.58 Closed-loop printhead error, load scan regs state.
111.59 Closed-loop printhead error, forward and reverse
capture times differ by too much.
111.60 Closed-loop printhead sweep error, check sweep
accuracy state.
111.61 Printhead drive control out of range due to an
external event beyond what the control is designed
to handle.
111.62 Closed-loop printhead error, off-resonant PI effort
state.
111.63 Timed out on POR sweep.
111.64 Attempted to exceed open loop drive limits.
111.65
111.66 Failed alignment of printhead.
111.67
111.68 Too many fake HSYNCs while aligning printhead.
111.69
4514-220, -230
Diagnostic information
90

Lexmark MS310 Series Specifications

General

Print Technology	Monochrome Laser
Processor Speed	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Recommended Monthly Page Volume	500 - 2, 500 pages
Connectivity	USB 2.0, Ethernet
First Page Out Time	As fast as 6.5 seconds
Print Resolution	1200 x 1200 dpi
Memory	128 MB
Duplex Printing	Standard
Input Capacity	250 sheets
Output Capacity	150 pages
Media Types Supported	Plain paper, envelopes, card stock, labels
Media Sizes	Letter, Legal, Executive, Statement, Oficio, A4, A5, A6, B5 (JIS), B6 (JIS), Envelope (No. 10, Monarch, DL, C5)
Operating Systems Supported	Windows, macOS, Linux
Dimensions	399 mm
