Lexmark MS310 Series Service Manual

230 paper jams
23y.xx paper jam messages
Error code Description Action
230.01 Sheet covering internal duplex sensor during warm
up.
Go to “Duplex service check” on page 73.
230.02 Paper jam around internal duplex.
230.03 Internal duplex sensor never made by leading edge of
page.
230.04 Page in duplexer ahead of current reversing page
never staged.
230.05 Internal duplex sensor never broke on the trailing
edge of the sheet.
230.07 Internal duplex sensor never broke from sheet ahead
of page.
230.09 Page in duplexer never picked.
230.10 Narrow page reversing into duplexer.
230.28 Bouncy duplex sensor never made.
232.03 Input sensor never detected sheet from internal
duplex path.
232.10 Feed error picking from the duplexer.
[x]‑page jam, remove tray 1 to clear duplex. [23y.xx]
CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot
component, allow the surface to cool before touching it.
1 Pull out the tray completely.
4514-220, -230
Diagnostic information
71

Lexmark MS310 Series Specifications

General

Print Technology	Monochrome Laser
Processor Speed	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Recommended Monthly Page Volume	500 - 2, 500 pages
Connectivity	USB 2.0, Ethernet
First Page Out Time	As fast as 6.5 seconds
Print Resolution	1200 x 1200 dpi
Memory	128 MB
Duplex Printing	Standard
Input Capacity	250 sheets
Output Capacity	150 pages
Media Types Supported	Plain paper, envelopes, card stock, labels
Media Sizes	Letter, Legal, Executive, Statement, Oficio, A4, A5, A6, B5 (JIS), B6 (JIS), Envelope (No. 10, Monarch, DL, C5)
Operating Systems Supported	Windows, macOS, Linux
Dimensions	399 mm
