Connector Locations 5-27
4025-XXX
BD8 Tray 1 Feeder↔I/O PWB↔ Offset Motor↔MCU PWB
The following table shows the signal names for this BD:
Signal Name Description
CL$FEED1 Switches Tray 1 Feed Clutch. 24V=Off. 0V=On
CL$RGATE Switches Registration Roll Clutch. 24V=Off. 0V=On
FSR##FEXIT Signal from the Fuser Exit Sensor. 5V=Not actuated. 0V=Actuated
CL$ICW Switches the CW Inverter Clutch. 24V=Off. 0V=On
CL$ICCW Switches the CCW Inverter Clutch. 24V=Off. 0V=On
OMOT$FWD Switches the Offset Motor forward.
OMOT$REV Switches the Offset Motor in reverse.
SNR#FUT Signal from the Face Up Sensor. 5V=Not actuated. 0V=Actuated
SNR#STK Signal from the Full Stack Sensor. 5V=Not actuated. 0V=Actuated
SOL$EGATE Switches the Exit Gate Solenoid. 24V=Off. 0V=On
SNR##SIZE1 Analog signal from the Tray 1 Sensor. 0VDC ~ 5VDC
SNR#REGI Signal from the Registration Sensor. 5V=Not actuated. 0V=Actuated
SNR#NOP1 Signal from the Tray 1 No Paper Sensor. 5V=Not actuated. 0V=Actuated
SNR#LVL1 Signal from the Tray 1 Level Sensor. 5V=Not actuated. 0V=Actuated
To Next Page
