Chapter 5 - Parameter List
61
Keypad Display Setting Range
Code
Description
LCD 7-Segment
LCD 7-Segment
Units
Factory
Default
Adj.
During
Run
Page
1.5kW 1
2.2kW 2
3.7kW 3
5.5kW 4
7.5kW 5
11.0kW 6
15.0kW 7
18.5kW 8
22.0kW 9
30.0 kW 10
37.0 kW 11
45.0 kW 12
55.0 kW 13
75.0 kW 14
FU2-31
Number of Motor Poles Pole number 31 2 to 12 1 4 No 104
FU2-32
Rated Motor Slip Rated-Slip 32 0 t o10 [Hz] 0.01
No 104
FU2-33
Rated Motor Current
(RMS)
Rated-Curr 33 1 to 200 [A] 1 No 104
FU2-34
No Load Motor Current
(RMS)
Noload-Curr 34 0.5 to 200 [A] 1 No 104
FU2-35
Motor Rated Voltage Motor Volt 35 180..460 [V] No 104
FU2-36
Motor Efficiency Efficiency 36 70 to 100 [%] 1
20
No 104
FU2-37
Load Inertia
Inertia rate 37 0 to 1 1 0 No 104
FU2-38
Carrier Frequency Carrier freq 38 1 to 15 [kHz] 1 5 [kHz] Yes
106
V/F 0
Slip comp 1
Sensorless_S 2
Sensorless_T 3
Vector_SPD 4
FU2-39
Control Mode Selection Control mode 40
Vector_TRQ 5
- V/F No 106
No 0
All 1
Rs + Lsigma 2
Enc Test 3
FU2-40
Auto Tuning Auto tuning 41
Tr 4
- No No
FU2-41
21
Stator Resistance of
Motor
Rs 42 0 to (depend on FU2-30) [ohm] 0.001
No
FU2-42
Leakage Inductance of
Motor
Lsigma 44 0 to (depend on FU2-30) [mH] 0.001
No
FU2-43
Stator Inductance of
Motor
Ls 43 0 to (depend on FU2-30) [mH]
22
No
108
19
The rated motor is automatically set according to the inverter model name. If different, set the motor capacity connected.
20
This value is automatically entered according to the rated motor set in FU2-30. If different, set the correct value of the motor.
21
Code FU2-41 through FU2-46 appears only when FU2-39 is set to ‘Sensorless_X’ or ‘Vector_XXX’.
22
This value is automatically entered according to the rated motor set in FU2-30. If different, set the correct value of the motor.
