LG SV-iS5 User Manual

Chapter 5 - Parameter List
62
Keypad Display Setting Range
Code
Description
LCD 7-Segment
LCD 7-Segment
Units
Factory
Default
Adj.
During
Run
Page
FU2-44
Rotor Time Constant Tr 44 0 to (depend on FU2-30) [mS] No
FU2-45
P Gain for Sensorless
Control
SL P-gain 45 0 to 32767 1 1000 Yes
109
FU2-46
I Gain for Sensorless
Control
SL I-gain 46 0 to 32767 1 100 Yes
109
No 0
FU2-47
PID Operation Selection
Proc PI mode
47
Yes 1
- No No 110
FU2-48
23
PID F Gain PID F-gain 48 0 to 999.9 [%] 0.1
0 [%] Yes
None 0
Keypad-1 1
Keypad-2 2
V1 3
I 4
FU2-49
PID Auxiliary Reference
Mode Selection
Aux Ref Mode
49
V2 5
- None No
FU2-50
PID Output Direction
Selection
PID Out Dir 50 Target freq. 0 - Target freq.
No
110
I 0
V1 1 FU2-51
PID Feedback Signal
Selection
PID F/B 51
V2 2
- I No
FU2-52
P Gain for PID Control PID P-gain 52 0 to 999.9 [%] 0.1
1.0 [%] Yes
FU2-53
I Gain for PID Control PID I-time 53 0 to 32.0 [sec] 0.1
10.0 [sec]
Yes
FU2-54
D Gain for PID Control PID D-time 54 0 to 1000 [msec] 0.1
0.0 [msec]
Yes
FU2-55
High Limit Frequency for
PID Control
PID limit-H 55 0 to 300.00 [Hz] 0.01
60.00 [Hz]
Yes
FU2-56
Low Limit Frequency for
PID Control
PID limit-L 56 0 to 300.00 [Hz] 0.01
0.00 [Hz]
Yes
110
No 0
FU2-57
PID Output Inversion PID Out Inv. 57
Yes 1
- No No
FU2-58
PID Output Scale PID Out Scale
58 0.1 to 999.9 [%] 0.1
100 [%]
No
FU2-59
PID P2 Gain PID P2-gain 59 0 to 999.9 [%] 0.1
100 [%]
No
FU2-60
P Gain Scale P-gain Scale 60 0 to 100 [%] 0.1
100 [%]
No
111
FU2-69
Accel/Decel Change
Frequency
Acc/Dec ch F
69 0 to FU1-20 0.00 [Hz]
No 114
Max freq 0
FU2-70
Reference Frequency for
Accel and Decel
Acc/Dec freq 70
Delta freq 1
- Max freq
No 114
0.01 [sec] 0
0.1 [sec] 1
FU2-71
Accel/Decel Time Scale
Time scale 71
1 [sec] 2
0.01
0.1 [sec]
Yes
114
FU2-72
Power On Display PowerOn disp
72 0 to 12 1 0 Yes
114
Voltage 0
FU2-73
User Display Selection User disp 73
Watt 1
- Voltage
Yes
115
FU2-74
Gain for Motor Speed
Display
RPM factor 74 1 to 1000 [%] 1 100 [%]
Yes
115
23
Code FU2-48 through FU2-62 appears only when FU2-47 is set to ‘Yes’.
