Chapter 5 - Parameter List
73
Keypad Display Setting Range
Code
Description
LCD 7-Segment
LCD 7-Segment
Units
Factory
Default
Adj.
During
Run
Page
EXT-31
Multi-function Output
Terminal ‘Q2’ Define
Q2 define 31 - FDT-2 Yes
EXT-32
Multi-function Output
Terminal ‘Q3’ Define
Q3 define 32
Same as Above
- FDT-3 Yes
140
Frequency 0
Current 1
Voltage 2
DC link Vtg 3
EXT-34
LM (Load Meter) Output
Selection
LM mode 34
Torque 4
- Current
Yes
140
EXT-35
LM Output Adjustment LM adjust 35 10 to 200 [%] 1 100 [%]
Yes
140
Frequency 0
Current 1
Voltage 2
DC link Vtg 3
EXT-40
AM1 (Analog Meter 1)
Output Selection
AM1 mode 40
Torque 4
- Frequency
Yes
EXT-41
AM1 Output Adjustment
AM1 adjust 41 10 to 200 [%] 1 100 [%]
Yes
Frequency 0
Current 1
Voltage 2
DC link Vtg 3
EXT-42
AM2 (Analog Meter 2)
Output Selection
AM2 mode 42
Torque 4
- DC link Vtg
Yes
EXT-43
AM2 Output Adjustment
AM2 adjust 43 10 to 200 [%] 1 100 [%]
Yes
141
EXT-50
Speed Limit Level Speed Limit 44 0 to 100 [%] 0.1
100 [%]
No
EXT-51
Speed Limit Bias Speed Bias 45 0 to 200 [%] 0.1
100 [%]
No
EXT-52
Speed Limit Gain Speed Gain 46 1 to 10 1 1 No
Reverse 0
EXT-53
Speed Limit Direction Speed Dir 47
Forward 1
- Forward
No
142
EXT-54
Zero Speed Detection
Level
ZSD Level 48 0 to 120 [Hz] 0.01
2 [Hz] Yes
EXT-55
Zero Speed Detection
Bandwidth
ZSD Band 49 0 to 5 [Hz] 0.01
1 [Hz] Yes
144
EXT-56
Torque Detection Level TD Level 50 0 to 150 [%] 0.1
100 [%]
Yes
EXT-57
Torque Detection
Bandwidth
TD Band 51 0 to 10 [%] 0.1
5 [%] Yes
144
EXT-99
Return Code Not displayed
99 Not available - 1 Yes
-
