Image Studio Software
4
C-DiGit User Manual 4-45
Data Analysis (Shapes and Annotation Ribbons)
Add and Manipulate Shapes Manually
1. Click the Shapes tab to open the Shapes ribbon.
2. Click Add Rectangle to add a rectangle to the image or Add Ellipse to add an
ellipse. Click in the center of a feature to place the rectangle or ellipse around
it. After adding the desired shapes, click Select or press the Esc key on your
keyboard to return the cursor to the selection tool.
3. To move or resize a shape, select the shape by clicking on it once. Dotted lines
indicate the shape is selected.
a. To move the shape, drag the four-pointed cursor within the selection shape.
b. To resize the shape, hover over any corner or side of the shape. Drag the
double-sided arrow to resize.
Note: To activate the double-sided arrow, the cursor must be on the
selection tool (click Select in the Shapes group or press the Esc key on the
keyboard).
