Image Studio Software
4
C-DiGit User Manual 4-28
Viewing and Manipulating Image Data
The rightmost panel in the main window contains an area that has three tabbed
panels that allow you to view and/or manipulate the selected images; Image Look
Up Tables (LUTs), Profiles, and Concentration.
Image LUTs
The Look Up Table Panel (or LUT Panel) allows you to edit the parameters that are
used to display the selected image in the image view.
You can view the Image Look Up Tables as either slider bars (the default view,
below left) or as histograms overlaid with a curve (below right). To hide this view,
click the double arrows in the top right corner.
