Lighthouse SOLAIR 3350 - Sample Printouts of Standard Reports

Lighthouse SOLAIR 3350, 5350 Gen E Operating Manual
6-74 248083387-1 Rev 10
Sample Printouts of Standard Reports
Figure 6-94, Figure 6-95 and Figure 6-96 are examples of a Federal
Standard Ft3, ISO 14644-1 and EU GMP 2009 reports.
Note: If a recipe is
loaded, the name of the
recipe will be printed on
the report.
Figure 6-94 Sample Federal Standard ft
3
report
*************
Fed Standard 209_Ft^3
**SOLAIR 3350**
Serial #: 130704005
Targeted Class: 10000
Room Area: 10.00 ft^2
Room Stat: Operational
Air Flow: Unidirect
Min Loc: 2
Min Samples/Room: 5
Recipe: FED_TEST
-----
07/10/2013, 12:35:47
-----
Particle Size: 0.3
Cumulative, p/ft^3
Vol Req: 0.100 ft^3
Concen Limit: 30800
-----
Loc Samples AvgConcen
LOC001 5 8003.5
LOC002 5 6524.5
-----
Mean: 7264.0
StdDev: 1045.8
StdError: 739.5
95% UCL: 11930.2
Min Vol: 1.467 ft^3
-----
Particle Size: 0.5
Cumulative, p/ft^3
Vol Req: 0.100 ft^3
Concen Limit: 10000
-----
Loc Samples AvgConcen
LOC001 3 328.4
