Lighthouse SOLAIR 3350, 5350 Gen E Operating Manual
4-6 248083387-1 Rev 10
Peripheral
Interface
Connector
The back of the SOLAIR also contains a round, Peripheral Interface
Connector (PIC) that can be used to connect an external peripheral
device such as an alarm buzzer, alarm light or a remote start/stop
controller.
The PIC pin-outs are displayed in Table 4-2.
Using Report
Parameters
The REPORTS screen is not just for printing reports. The data provided
on the screen when various parameters are set will allow users to setup
the counter in order to meet the requirements necessary for the report
used in the Standard Operating Procedure.
Note:
Due to rounding of
values, occasionally the
user may need to increase
the sample volume in order
to meet the requirements.
For each report type, as the user changes the Room Area, the Class
Level, and sometimes the Air Flow or the Room Status, the values for
the Minimum Locations, Minimum Samples and Minimum Volume
may change and will be correctly calculated for the requirements for
each report type.
By confirming that the setup of the counter meets the requirements
indicated on this screen, the user will ensure that the samples run will
meet the requirements of the selected report.
Table 4-2 PIC Connector Pin-Outs
Pin Connection
1 24 VDC
2GND
3Alarm+
4Alarm-
5 Start/Stop
6 Not Connected
7 Not Connected
8GND
