LIGHTMED TruScan Pro – Operator’s Manual Rev. No. 01 Page 14 of 109
9
Joystick connector
This is used to supply feedback or monitor joystick
movement during operation.
10
Service port
Provides access to the micro controller unit (MCU) board
for system diagnostic and system upgrades.
11
Main power inlet
This socket is used to connect the laser console to the
main power. The input voltage is 100 – 250 VAC. Two 8-
Ampere (8 A) fuses are used to protect against power
surge and overcurrent.
12
Scan delivery
This connector receives signals from the LDUs for spot
size position and provides power to galvomotors.
13
Touch screen monitor
The touch screen monitor port is a USB 3.0 type
connection that is reserved to be used with the system’s
control module which receives signals from the user
interface.
14
Display port
Sends signals to the monitor to display the system’s user
interface.
15
USB 3.0 port
This is a standard USB 3.0 type connection available to
use with accessories such as 3D mouse and other
upgrades.
When the TruScan Pro laser is first turned on, the microprocessor performs various checks to
ensure that the laser is functioning properly. If the self-check test passes, then the unit goes into
STANDBY mode. In addition to these safety features, there are also several features that have
been built-in to the TruScan Pro laser system:
• All the safety controls are in place to prevent the operator from unintentionally firing the laser.
• This laser system is equipped with protective housing covers to prevent exposure to laser
emissions. Special tools are required to remove the housing covers and only authorized and
trained Service Technicians are permitted to remove them.
• There are optical safety filters built into the laser system to protect the operator’s eyes from
being exposed to the laser beam when using the equipment.
• This laser system is designed to comply with the electrical safety standards for ground
connections and ground leakages.
• If the laser system is not used or no controls are operated for 10 minutes, the system will go
into STANDBY mode.
• The console produces an audible warning whenever the laser fires.
NOTE: With these controls and safety features, the TruScan Pro laser system is a very safe
instrument when used correctly and as indicated in this manual.
