LIGHTMED TruScan Pro – Operator’s Manual Rev. No. 01 Page 23 of 109
3.2 LDU Specifications
3.2.1 Slit Lamp Specifications
Item
Description
Model
CSO SL950 slit lamp
Microscope
Galilean
Pattern scanning
• Single
• Line
• Square (2 x 2, 3 x 3, 4 x 4, 5 x 5)
• Triangle
• Circle (single, triple)
• Equal spacing (2 x 2, 3 x 3, 4 x 4, 5 x 5)
Spot sizes (µm)
• Single spot: 50, 100, 200, 300, 400 and 500
• Multi-spot: 100, 200, 300, 400, and 500 selectable on zoom
assembly on slit lamp
Focus plane
All spot sizes parfocal to slit lamp focus plane
Exposure duration (ms)
• Single spot: 10 to 3,000
• Multi-spot: 10 to 50
Repeat interval
• Single spot: selectable from OFF, 10 to 3,000 ms and greater-
than or equal to (≥) exposure duration, in the same discrete
steps as exposure duration
• Multi-spot: OFF
Slit lamp
The TruScan module is mounted between the binocular and
objective lens
Beam divergence
Cone angle of 20°
Magnification set
6-step drum rotation
Eyepiece
12.5X
Magnification ratio
• 5X
• 8X
• 14X
• 24X
• 36X
PD range (mm)
48.5 to 80
Diopter adjustment
±8
Slit illumination
LED XLamp® XM-L2 2.85V 10W
Slit width (mm)
0 to 14 (SL950)
Slit length (mm)
1 to 14
Slit apertures (mm)
• 0.3
• 5.5
• 9
• 14
Slit angles
±90°
Filters
• Blue
• Red
• Green (red-free)
