LIGHTMED TruScan Pro – Operator’s Manual Rev. No. 01 Page 92 of 109
Installation Report
7. INSTALLATION CHECKLIST N/A
1. All parts received and checked OK.
2. No damage to instrument packaging.
3. Verify operating environment and electrical power requirements.
4. Accessories and modules were unopened upon arrival.
5. Accessories and modules were received in good condition.
6. Modules are assembled accordingly during installation.
7. Table turns ON, LED lights up when the power cable is plugged in.
8. Verify the vertical ophthalmic table movement/operation.
1. Illumination lamp controls check OK.
2. 4-filter wheel settings check OK.
3. Slit width fully opens 5 aperture settings check OK.
4. At 13 mm (biggest) aperture setting, slit forms a full circular spot.
5. Slit is fully adjustable, from open to closed positions.
6. There is no illumination when the slit is fully closed.
7. A narrow slit can rotate ± 90° vertically.
8. Eyepieces fit firmly into binoculars.
9. Eyepieces can be fully adjusted and set to correct diopters.
10. Vertical slit lamp movement with joystick checks OK.
11. Side slit lamp movement with joystick checks OK.
12. Forward slit lamp movement with joystick checks OK.
13. Slit lamp movements with joystick are smooth (no tension or friction).
14. Illumination tower and laser arm can be swung from side to side.
1. Chinrest is securely tightened to the control box, not loose.
2. Chinrest height is adjustable, vertical movement is smooth.
3. Chinrest handles are fixed firmly to posts.
4. Fixation lamp is operational.
5. Fixation lamp can be moved in any direction.
1. All cables and connections are plugged into laser console.
2. The laser console powers ON upon system start-up.
3. Verify no error or warning message occur upon system start-up.
4. All patterns on the pattern scanner system are functional.
5. Spot size are adjustable on the slit lamp system.
6. LCD screen responds and is calibrated to touch.
