LIGHTMED TruScan Pro – Operator’s Manual Rev. No. 01 Page 54 of 109
8 dots
11 dots
1.0
5 dots
7 dots
9 dots
1.5
4 dots
6 dots
8 dots
2.0
3 dots
5 dots
6 dots
• ¼ circle parameters (rotation can be adjusted from 0 to 355° in 5°-
increments):
Spot Size
(µm)
Spacing
(Φ)
Radius (µm)
1,000
1,500
2,000
200
0
8 dots
12 dots
16 dots
0.5
5 dots
8 dots
11 dots
1.0
4 dots
6 dots
8 dots
