3. Product Overview HDMI20-OPTC series – User's Manual 18
Application Example with Break-out Connector
receiver pair with only one Neutrik opticalCON DUO cable. See the application example below.
The transmitter’s laser driver sends the signal through
Channel A. Channel B is directly connected to the
unit. Any optical signal can be transferred through this
channel in any direction.
The receiver’s laser sensor gets the signal through
Channel B. Channel A is directly connected to the break-
Any optical signal can be transferred through this
channel in any direction.
INFO: Break-out connector can be used in the same
way in all variants.
B
B A
B
B A
A
B A
A
B A
LC-LC fiber
optical cable
LC-LC fiber
optical cable
Neutrik opticalCON up to 700m
Source 1. Sink 1.
Sink 2.
Source 2.
A/V Video Signal 1.
A/V Video Signal 2.
HDMI
HDMI
HDMI
HDMI
Transmitter side
Receiver side
B
A
A
B
A
B
A
B A
A
B
B
LC-LC fiber
optical cable
LC-LC fiber
optical cable
Neutrik opticalCON up to 700m
Transmitter side Receiver side
Optical Interface
embedded audio, RS-232 and Ethernet signals. For more details about the supported cable extension
distances see Maximum Extension Distances section.
Port Diagram of Optical Interface
channel A and channel B. Since Lightware
INFO: Red line shows the main direction of the video signal. The blue line represents the optical signal via
B
A
HDMI
Out
B
A
A
B
Break-out
connector
Break-out
connector
Neutrik
connector
HDMI20-OPTC-RX220HDMI20-OPTC-TX220
Other ber device
Neutrik
connector
HDMI
splitter
HDMI
Input 1.
HDMI
Input 2.
HDMI
splitter
HDMI
Output
2.
Video
converer
HDMI
Output
1A.
HDMI
Output
1B.
Other ber device
