10. Appendix HDMI20-OPTC series – User's Manual 71
Content of Backup File
Transmitter Receiver
Port name
Crosspoint settings
Port name Port name
Autoselect settings
Signal type Signal type
Port name Port name
Autoselect settings
Signal type Signal type
+5V Enable +5V Enable
RS-232 RS-232
Port name Port name
RS-232 mode RS-232 mode
Parity
Parity
Control protocol Control protocol
Ethernet Ethernet
Port name (P1, P2, P3, P4) Port name (P1, P2, P3, P4)
Enable (P1, P2) Enable (P1, P2)
EDID Settings EDID Settings
User EDID U1-14 User EDID U1-13
Emulated EDIDs Emulated EDIDs
Event Manager Event Manager
Events 1-20 Events 1-20
Front Panel Control Front Panel Control
Display brightness
Rotary direction
Control lock
Dark mode enable Dark mode enable
Transmitter Receiver
Dark mode delay Dark mode delay
Device label Device label
Network Network
DHCP enable DHCP enable
Static IP address Static IP address
Static network mask Static network mask
Static gateway address Static gateway address
Conversion mode
O1 +5V Enable
O2 +5V Enable
O3 +5V Enable
Factory Default Settings
Factory Default Settings of the Transmitter
Transmitter
Video settings: HDMI Input
Port number I1, I2
Port name HDMIIN1, HDMIIN2
Unmuted
Unlocked
Crosspoint settings I1:O1; I1:O2
Video settings: Optical Output
Port name OPTOUT
Port number O1
Unmuted
Unlocked
Autoselect settings Disabled
Signal type Auto
Video settings: HDMI Output
Port name HDMIOUT
Port number O2
Unmuted
Unlocked
Autoselect settings Disabled
Signal type Auto
+5V Enable Always on
Transmitter
Front panel settings
Display brightness 10
Rotary direction
Control lock Unlock
Dark mode enable, dark mode
delay
Disable
General
Device label HDMI20-OPTC-TX220-PRO
Network
DHCP enable Disabled
Static IP address 192.168.0.101
Static network mask 255.255.255.0
Static gateway address 192.168.0.1
Conversion mode No conversion
Always on
Always on
O3 +5V Enable (Output 2) Always on
