10. Appendix HDMI20-OPTC series – User's Manual 72
Factory Default Settings of the Receiver
Receiver
Video settings: Optical Input
Port name OPTIN
Port number I1
 Unmute
 Unlock
Video settings: HDMI Output
Port name HDMIOUT1A, HDMIOUT1B, HDMIOUT2
Port number O1, O2, O3
 Unmuted
 Unlocked
Signal type Auto
+5V Enable Always on
Conversion mode* No conversion
HDCP mode Depends on input
Front panel
Control lock Unlock
Dark mode enable, dark
mode delay
Disable
General
Device label HDMI20-OPTC-RX220-PRO
Network
DHCP enable Disabled
Static IP address 192.168.0.102
Static network mask 255.255.255.0
Static gateway address 192.168.0.1
* This setting is only available at HDMIOUT1A (O1) port.
Factory Default Settings of the Transmitter and the Receiver
Transmitter Receiver
RS-232
Port name Local
RS-232 mode Pass-through
Baud rate 57600
Data bits 8
Stop bits N
Parity 1
Command injection enable Disabled
Port 8001
Control protocol 
Ethernet
Port name (P1, P2, P3, P4) Ethernet, Ethernet, OPT, CPU
Enable (P1, P2) Enable
EDID Settings
Emulated EDIDs D1* for all inputs
Front panel
Display brightness 10
Rotary direction 
Control lock Unlock
Dark mode enable, dark mode
delay
Disable

Conversion mode No conversion
 Always on
 Always on
O3 +5V Enable (Output 2) Always on
*The default emulated EDID is D1 both the transmitter and the receiver.
The EDID, which is from the attached monitor of HDMIOUT1A (O1)
port of the receiver, is copied to all the input ports.




