22
Address (15 bits)
Bits
Description
0x0209
15 – 1
0
BSIGI[14:0]: TxTSP BIST signature, channel I, LSB.
BSTATE: TxTSP BIST state indicator
0 – BIST is not running
1 – BIST in progress
Read only
0x020A
15 – 8
7 – 0
BSIGQ[7:0]: TxTSP BIST signature, channel Q, LSB.
BSIGI [22:15]: TxTSP BIST signature, channel I, MSB.
Read only
0x020B
15
14 – 0
Reserved
BSIGQ[22:8]: TxTSP BIST signature, channel Q, MSB.
Read only
0x020C
15 – 0
DC_REG[15:0]: DC data source for test purposes.
Possible values: 2^16-1 – 0 (default)
Default: 00000000 00000000
