2.7 RX/TX GFIR3 Coefficient Memory
The general purpose digital FIR filter (GFIR3) coefficients are stored in the following table.
Table 8 Memory space used to store TxGFIR3 coefficients
Address (15 bits)
Bits
Description
Tx: 0x0300 – 0x0307
Rx: 0x0500 – 0x0507
8 x 16
Tx(Rx)3CMB0a[7:0][15:0]: Coefficients memory bank 0a for TxGFIR2/RxGFIR3.
Tx: 0x0308 – 0x030F
Rx: 0x0508 – 0x050F
8 x 16
Tx(Rx)3CMB1a[7:0][15:0]: Coefficients memory bank 1a for TxGFIR2/RxGFIR3.
Tx: 0x0310 – 0x0317
Rx: 0x0510 – 0x0517
8 x 16
Tx(Rx)3CMB2a[7:0][15:0]: Coefficients memory bank 2a for TxGFIR2/RxGFIR3.
Tx: 0x0318 – 0x031F
Rx: 0x0518 – 0x051F
8 x 16
Tx(Rx)3CMB3a[7:0][15:0]: Coefficients memory bank 3a for TxGFIR2/RxGFIR3.
Tx: 0x0320 – 0x0327
Rx: 0x0520 – 0x0527
8 x 16
Tx(Rx)3CMB4a[7:0][15:0]: Coefficients memory bank 4a for TxGFIR2/RxGFIR3.
Tx: 0x0328 – 0x033F
Rx: 0x0528 – 0x053F
24 x 16
Reserved
Tx: 0x0340 – 0x0347
Rx: 0x0540 – 0x0547
8 x 16
Tx(Rx)3CMB0b[7:0][15:0]: Coefficients memory bank 0b for TxGFIR2/RxGFIR3.
Tx: 0x0348 – 0x034F
Rx: 0x0548 – 0x054F
8 x 16
Tx(Rx)3CMB1b[7:0][15:0]: Coefficients memory bank 1b for TxGFIR2/RxGFIR3.
Tx: 0x0350 – 0x0357
Rx: 0x0550 – 0x0557
8 x 16
Tx(Rx)3CMB2b[7:0][15:0]: Coefficients memory bank 2b for TxGFIR2/RxGFIR3.
Tx: 0x0358 – 0x035F
Rx: 0x0558 – 0x055F
8 x 16
Tx(Rx)3CMB3b[7:0][15:0]: Coefficients memory bank 3b for TxGFIR2/RxGFIR3.
Tx: 0x0360 – 0x0367
Rx: 0x0560 – 0x0567
8 x 16
Tx(Rx)3CMB4b[7:0][15:0]: Coefficients memory bank 4b for TxGFIR2/RxGFIR3.
Tx: 0x0368 – 0x037F
Rx: 0x0568 – 0x057F
24 x 16
Reserved
Tx: 0x0380 – 0x0387
Rx: 0x0580 – 0x0587
8 x 16
Tx(Rx)3CMB0c[7:0][15:0]: Coefficients memory bank 0c for TxGFIR2/RxGFIR3.
Tx: 0x0388 – 0x038F
Rx: 0x0588 – 0x058F
8 x 16
Tx(Rx)3CMB1c[7:0][15:0]: Coefficients memory bank 1c for TxGFIR2/RxGFIR3.
Tx: 0x0390 – 0x0397
Rx: 0x0590 – 0x0597
8 x 16
Tx(Rx)3CMB2c[7:0][15:0]: Coefficients memory bank 2c for TxGFIR2/RxGFIR3.
Tx: 0x0398 – 0x039F
Rx: 0x0598 – 0x059F
8 x 16
Tx(Rx)3CMB3c[7:0][15:0]: Coefficients memory bank 3c for TxGFIR2/RxGFIR3.
Tx: 0x03A0 – 0x03A7
Rx: 0x05A0 – 0x05A7
8 x 16
Tx(Rx)3CMB4c[7:0][15:0]: Coefficients memory bank 4c for TxGFIR2/RxGFIR3.
Tx: 0x03A8 – 0x03BF
Rx: 0x05A8 – 0x05BF
24 x 16
Reserved
