2.4 TxTSP(A/B) Configuration Memory
The block diagrams of TxTSPA and TxTSPB modules are exactly the same. The control
structure is shown in Figure 22. The tables in this chapter describe the control registers of
TxTSPA and TxTSPB modules.
There is one BIST logic per TxTSPA and TxTSPB. The BIST control structure is
shown in Figure 25.
Table 4 TxTSP configuration memory
Address (15 bits)
Bits
Description
0x0200
15 10
9
8 7
6
5
4
3
2
1
0
Reserved
TSGFC: TSG full scale control.
0 -6dB (default)
1 Full scale
TSGFCW: Set frequency of TSG's NCO.
DC TSG NCO frequency
========================
00 do not use
01 TSP clk/8 (default)
10 TSP clk/4
11 do not use
TSGDCLDQ: Load TSG DC Q register with value from DC_REG[15:0].
0 No action (default)
0-to-1 positive edge loads TSG's DC register Q.
TSGDCLDI: Load TSG DC I register with value from DC_REG[15:0].
0 No action (default)
0-to-1 positive edge loads TSG's DC register I.
TSGSWAPIQ: Swap signals at test signal generator's output.
0 Do not swap (default)
1 Swap I an Q signal sources comming from TSG
TSGMODE: Test signal generator mode.
0 NCO (default)
1 DC source
INSEL: Input source of TxTSP:
0 LML output (default)
1 Test signal generator
BSTART: Starts TxTSP built in self test. Keep it at 1 one at least three clock cycles.
0 (default)
0-to-1 positive edge activates BIST
EN: TxTSP modules enable.
0 Disabled
1 Enabled (default)
Default: 00000000 10000001
0x0201
15 11
10 0
Reserved
GCORRQ[10:0]: Gain corrector value, channel Q. Unsigned integer.
Possible values are 0 2047, default is 2047
Default: 00000111 11111111
0x0202
15 11
10 0
Reserved
GCORRI[10:0]:Gain corrector value, channel I Unsigned integer.
Possible values are 0 to 2047, default is 2047
Default: 00000111 11111111
0x0203
15
14 12
11 0
Reserved
HBI_OVR[2:0]: HBI interpolation ratio. Interpolation ratio is 2
HBI_OVR+1
.
000 Interpolation ratio is 2 (default)
001 Interpolation ratio is 4
010 Interpolation ratio is 8
011 Interpolation ratio is 16
100 Interpolation ratio is 32
111 Bypass
IQCORR[11:0]: Phase corrector value (tan(Alpha/2)). Integer, 2's complement.
Possible values are -2048 to 2047, default is 0
Default: 00000000 00000000
