Lime Microsystems LMS7002MR3 - Page 23

19
Address (15 bits)
Bits
Description
TX(A/B): 0x0257
RX(A/B): 0x0457
15 – 0
FCW10[15:0]: NCO frequency control word register 10, when MODE = 0. LSB part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0258
RX(A/B): 0x0458
15 – 0
FCW11[31:16]: NCO frequency control word register 11, when MODE = 0. MSB
part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0259
RX(A/B): 0x0459
15 – 0
FCW11[15:0]: NCO frequency control word register 11, when MODE = 0. LSB part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x025A
RX(A/B): 0x045A
15 – 0
FCW12[31:16]: NCO frequency control word register 12, when MODE = 0. MSB
part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x025B
RX(A/B): 0x045B
15 – 0
FCW12[15:0]: NCO frequency control word register 12, when MODE = 0. LSB part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x025C
RX(A/B): 0x045C
15 – 0
FCW13[31:16]: NCO frequency control word register 13, when MODE = 0. MSB
part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x025D
RX(A/B): 0x045D
15 – 0
FCW13[15:0]: NCO frequency control word register 13, when MODE = 0. LSB part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x025E
RX(A/B): 0x045E
15 – 0
FCW14[31:16]: NCO frequency control word register 14, when MODE = 0. MSB
part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x025F
RX(A/B): 0x045F
15 – 0
FCW14[15:0]: NCO frequency control word register 14, when MODE = 0. LSB part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0260
RX(A/B): 0x0460
15 – 0
FCW15[31:16]: NCO frequency control word register 15, when MODE = 0. MSB
part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0261
RX(A/B): 0x0461
15 – 0
FCW15[15:0]: NCO frequency control word register 15, when MODE = 0. LSB part.
Reserved, when MODE = 1.
Default: 00000000 00000000
