Lime Microsystems LMS7002MR3 - Page 22

18
Address (15 bits)
Bits
Description
TX(A/B): 0x0246
RX(A/B): 0x0446
15 – 0
FCW2[31:16]: NCO frequency control word register 2, when MODE = 0. MSB part.
PHO2[15:0]: NCO Phase offset register 2, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0247
RX(A/B): 0x0447
15 – 0
FCW2[15:0]: NCO frequency control word register 2, when MODE = 0. LSB part.
PHO3[15:0]: NCO Phase offset register 3, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0248
RX(A/B): 0x0448
15 – 0
FCW3[31:16]: NCO frequency control word register 3, when MODE = 0. MSB part.
PHO4[15:0]: NCO Phase offset register 4, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0249
RX(A/B): 0x0449
15 – 0
FCW3[15:0]: NCO frequency control word register 3, when MODE = 0. LSB part.
PHO5[15:0]: NCO Phase offset register 5, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x024A
RX(A/B): 0x044A
15 – 0
FCW4[31:16]: NCO frequency control word register 4, when MODE = 0. MSB part.
PHO6[15:0]: NCO Phase offset register 6, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x024B
RX(A/B): 0x044B
15 – 0
FCW4[15:0]: NCO frequency control word register 4, when MODE = 0. LSB part.
PHO7[15:0]: NCO Phase offset register 7, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x024C
RX(A/B): 0x044C
15 – 0
FCW5[31:16]: NCO frequency control word register 5, when MODE = 0. MSB part.
PHO8[15:0]: NCO Phase offset register 8, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x024D
RX(A/B): 0x044D
15 – 0
FCW5[15:0]: NCO frequency control word register 5, when MODE = 0. LSB part.
PHO9[15:0]: NCO Phase offset register 9, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x024E
RX(A/B): 0x044E
15 – 0
FCW6[31:16]: NCO frequency control word register 6, when MODE = 0. MSB part.
PHO10[15:0]: NCO Phase offset register 10, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x024F
RX(A/B): 0x044F
15 – 0
FCW6[15:0]: NCO frequency control word register 6, when MODE = 0. LSB part.
PHO11[15:0]: NCO Phase offset register 11, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0250
RX(A/B): 0x0450
15 – 0
FCW7[31:16]: NCO frequency control word register 7, when MODE = 0. MSB part.
PHO12[15:0]: NCO Phase offset register 12, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0251
RX(A/B): 0x0451
15 – 0
FCW7[15:0]: NCO frequency control word register 7, when MODE = 0. LSB part.
PHO13[15:0]: NCO Phase offset register 13, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0252
RX(A/B): 0x0452
15 – 0
FCW8[31:16]: NCO frequency control word register 8, when MODE = 0. MSB part.
PHO14[15:0]: NCO Phase offset register 14, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0253
RX(A/B): 0x0453
15 – 0
FCW8[15:0]: NCO frequency control word register 8, when MODE = 0. LSB part.
PHO15[15:0]: NCO Phase offset register 15, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0254
RX(A/B): 0x0454
15 – 0
FCW9[31:16]: NCO frequency control word register 9, when MODE = 0. MSB part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0255
RX(A/B): 0x0455
15 – 0
FCW9[15:0]: NCO frequency control word register 9, when MODE = 0. LSB part.
Reserved, when MODE = 1.
Default: 00000000 00000000
TX(A/B): 0x0256
RX(A/B): 0x0456
15 – 0
FCW10[31:16]: NCO frequency control word register 10, when MODE = 0. MSB
part.
Reserved, when MODE = 1.
Default: 00000000 00000000
