4 Operation
Loading / Transporting
¾ Rotate the parking brake lever (1) in a
clockwise direction until it engages.
The parking brake is now applied.
¾ Switch off the engine.
¾ Remove the ignition key (2).
Loading / Transporting
Securing the hose pulley against
rolling up
1
2
3
4
5
d3921468
When fitting single auxiliary hydraulics, a hose
pulley (1) is located beneath the floorplate
(with double auxiliary hydraulics, a second
hose pulley (5) is fitted in mirror image).
WARNING
The hose pulleys are spring-biased.
For this reason, they must always be secured
against rolling up:
• Before disconnecting the hose line screw
joints at the lift mast connection point (e.g.
to remove the lift mast or remove the hose
pulley itself).
• For all other work on the hose pulleys in the
truck.
WARNING
The roll-up protection must not be opened on the
removed hose pulley.
If this cannot be avoided, reduce the spring tension
to 0 beforehand. Contact your authorised dealer.
¾ Open the bonnet.
¾ Open floor plate and secure it.
98 Operating Instructions – 394 807 10 01 EN – 07/2011
