Linde H40D - Self-Help; Opening the Cover to the Electrical System

Maintenance 5
Self-help
Self-help
Opening the cover to the electrical
system
Depending on the set-up, up to 40 fuses may
be installed in the electrical system in order to
protect it. The fuse box can be accessed after
removing the cover of the electrical system.
¾ Unscrew both handles(2).
¾ Take off the cover (1).
¾ Take off the fuse box cover.
Operating Instructions – 394 807 10 01 EN – 07/2011 191
