Maintenance 5
Hydraulics
¾ Unscrew the filter (5) for the hydraulic oil
tank from the filler neck.
¾ Remove the dipstick (7) from the breather
filter and attach it to the new filter.
¾ Screw in the filter and tighten i
t.
¾ Close the bonnet.
Check the bleeder
valve on the hy-
draulic oil tank f
or correct operation
NOTE
The breather fil
ter on the hydraulic oil tank is
fitted with a bre
ather valve, which causes the
tank to be at a sl
ight positive pressure.
ENVIRONMENT NOTE
Observe information regarding working with
consumables.
¾ Close the br
eather filter (1) and check
whether the
breather filter is seated cor-
rectly.
¾ Start the engine.
¾ Extend lift mast several times to the stop
and let it return.
¾ Switch off
the engine. Open the breather
filter (1) o
n the hydraulic oil tank.
Air must be heard to escape from the tank. If
no noise of air escaping is audible, replace the
breather filter.
Operating Instructions – 394 807 10 01 EN – 07/2011 179
