5 Maintenance
Engine
¾ Compress the valve (1) and remove the
remaining dust.
¾ If the value is damaged, replace it.
¾ Close the bonnet.
Changing the brea
ther filter for the
charge air pressu
re regulator
ENVIRONMENT NOTE
Observe information regarding working with
consumables.
¾ Open the bonnet.
Both filters ar
e located at the back right-hand
side next to th
e engine.
¾ Detach hoses (5) and (9) from the filter.
¾ Pull the filter (6) upwards out of the rubber
grommet (7) in the support (8).
¾ Dispose of fil
ter in an environmentally
friendly man
ner.
¾ Insert the new filter into the support up to the
stop.
¾ Slide on the hose (5) from above as far as
the step.
¾ Slideonthe
hose (9) from below as far as
the step.
¾ Check that the filter is properly seated.
¾ Change the second filter (10) in the same
way.
142 Operating Instructions – 394 807 10 01 EN – 07/2011
