Linde H40D - Type Sheet H 40, as at 07;2011

6 Technical data
Type sheet H 40, as at 07/2011
Type sheet H 40, as at 07/2011
All data refers to standard equipment with a standard 3000 mm lift mast.
Please note the following:
1 Characteristics
1.1 Manufacturer Linde
1.2
Manufacturer’s type desig
nation
H40D
1.3 Drive Diesel
1.4
Operation
Seated
1.5
Load capacity/load
Q[kg]
4000
1.6
Load centre of gravity c [mm]
500
1.8 Load distance
x [mm]
483
1.9 Wheelbase
y [mm]
1998
2 Weight
2.1
Net weight kg
5785
2.2
Axle load with front/rear load
kg
8608/1177
2.3
Axle load without front/rear load
kg
2640/3145
3 wheels, chassis fr
ame
3.1
Front/rear tyres: polyurethane, rubber
SE (P)
3.2
Front tyre size
250–15
3.3
Rear tyre size
250–15
3.5
Number of wheels, front/rear (x = driven) 2x (4x)
1
/2
3.6 Front track width
b
10
[mm]
1221
2
3.7 Rear track width
b
11
[mm]
1122
4 Basic dimens
ions
4.1 Forward/backward fork tilt
α/β (°)
5.0/9.0
3
4.2
Lowered mast height
h
1
[mm]
2370
4
4.3 Free lift
h
2
[mm]
150
1
Bracketed value for twin tyres.
2
The track width may deviate from the indicated value, depending on the tyre variant.
3
L
ift height and equipment may change the backwards tilt.
4
With 150 mm free lift on standard lift mast.
208 Operating Instructions – 394 807 10 01 EN – 07/2011
