6 Technical data
Type sheet H 45 container, as at 07/2011
Type sheet H 45 container, as at 07/2011
All data refers to standard equipment with triplex 4045 mm lift mast.
Please observe the following:
1 Identification
1.1 Manufacturer Linde
1.2
Manufacturer’s type desig
nation
H45D
1.3 Drive Diesel
1.4
Operation
Seated
1.5
Load capacity/load
Q[kg]
4500
1.6
Load centre of gravity c [mm]
500
1.8 Load distance
x [mm]
483
1.9 Wheelbase
y [mm]
2038
2 Weight
2.1
Net weight kg
6355
2.2
Axle load with front/rear load
kg
9527/1328
2.3
Axle load without front/rear load
kg
2856/3499
3 Wheels, chassis fr
ame
3.1
Front/rear tyres: polyurethane, rubber
SE (P)
3.2
Front tyre size
28x12.5–15
3.3
Rear tyre size
250-15
3.5
Number of wheels, front/rear (x = driven)
2x/2
3.6 Front track width
b
10
[mm]
1190
47
3.7 Rear track width
b
11
[mm]
1122
4 Basic dimens
ions
4.1 Forward/backward fork tilt
α/β (°)
5.0/7.5
48
4.2
Lowered mast height
h
1
[mm]
2160
4.3 Free lift
h
2
[mm]
1310
4.4 Lift
h
3
[mm]
4045
4.5
Raised mast height
h
4
[mm]
4895
47
T
he track width may deviate from the indicated value, depending on the tyre variant.
48
Lift height and equipment may change the backwards tilt.
