Maintenance 5
Electrics
d3941363
1
2
¾ Inspect battery (1) for cracked housing,
raised plates and acid leaks.
¾ Unscrew sealing plugs (2) and check acid
level.
In the case of batteries with le
vel checking
inserts, the fluid must reach th
e bottom of the
insert, and for batteries wi
thout level checking
inserts, it must lie 10–15 mm
above the lead
plates.
¾ Any lack of fluid should only be made up
with distilled water.
¾ Remove any oxidation residues on the
battery terminals and then apply acid-free
grease.
¾ Retighten battery-termi
nal clips firmly.
¾ Check acid density with an acid siphon. The
density value must be 1.24-1.28 kg/l.
¾ Screw sealing plugs (2) back in.
¾ Close the bonnet.
Operating Instructions – 394 807 10 01 EN – 07/2011 173
