4 Operation
Standard equipment
¾ Take note of the switching symbols with
arrows.
¾ Unlock the joystick (4) (depending on the
version) by pressing the knob downwards.
¾ Push the joystick (4) forwards.
Clamp opens.
¾ Pull the joystick (4) backwards.
Clamp closes.
Once the joystick
has been released, it is
locked again.
64 Operating Instructions – 394 807 10 01 EN – 07/2011
