D9U001GKB-0101 19/150
Before tilting back, connect the backup battery to the control box according to
the following procedure.
Ensure the power cable is unplugged of power site!
1) Tilt the armchair and support the leg from the side (see Fig. 1).
2) On the bottom side of the base there is a disconnected supply connector
(highlighted in Fig. 2).
3) Plug the supply connector firmly to the vacant socket as far as it goes (Fig. 3
and 4).
4) Secure the plugged in connector by clicking the security frame, use a
screwdriver (Fig. 4).
