44/150 D9U001GKB-0101
If the chair is adjusted to the boarding position (downward movement),
objects may be pinched between the chassis cover and the column cover.
Therefore, it is forbidden to place any objects on the chassis cover.
4.7 Synchronous Adjustment of Foot Rests
• Vertical set up can be changed using the hand control.
• Footrests can be horizontally adjusted manually, where both footrests are
connected (coupled together). When pushing to one of the footrests, the
other one is adjusted too.
• Force of setting up can be adjusted using the screw for adjusting toughness
of footrests operation.
