D9U001GKB-0101 35/150
4.2 Motorized Adjustments (Remote control)
• Description with white ground provides the information which part will
move during setting up.
• The length of the stretched cable of manual control is 4 m (max).
Anti-shock position A
(memory function - automatically programmed factory
setting, cannot be changed)/ save memory location
Examination position
(memory function)
Height adjustment loading areas (up and down)
Back rest tilting with footrest at same time (The back
part down and footrest up / the back part up and
footrest down)
Foot rest tilting (up and down)
Position for getting on and out (a memory function)
Ultrasound scan position
(memory function)
Movement stop / position saved
The physician's choice (A, B, C) and his/her
individually set memory functions (with repeated
pushing down the signalling on the fixed foot
control occurs)
