LINET GRACIE - Image from the Video Colposcope

D9U001GKB-0101 53/150
4.13.2 Image from the video colposcope
After the chair is connected to power supply, initialization of the system of the
video colposcope starts. This condition is indicated by fast flashing of a greed
LED on the keyboard of the video colposcope as well as on the screen (duration
of initialization: ca. 15 sec.).
When both diodes start flashing slowly, the system is ready for use and the
video colposcope can be switched on.
Icon in the lower right corner informs whether the GRACIE chair is connected to
the doctor's PC.
If an image is transferred to the doctor's PC, the green arrows in the icon start
blinking.
The chair is not connected to the
PC.
The chair is connected to the PC.
