4.14.1 Summary of basic parts
1
Video colposcope
1a
Camera with LED diodes
1b
Video colposcope body
1c
Video colposcope handle with control panel
1d
Control panel
1e
Polarization filter control knob
2
Section of the video colposcope arm
3
Switch of input from the video colposcope or ultrasound
4
17" LCD screen
5a
LAN connector into PC
5b
VGA image input from external ultrasound
1
2
3
1c
1a
1b
1d
1e
5b
5a
4
