D9U001GKB-0101 41/150
4.5 Manipulating the chair
4.5.1 Using integrated wheels
It is essential that the chair travels without any person sitting in it.
Manipulation wheel is used only for chair travel within a room for the purposes
of cleaning the area under the chair, setting up the chair in the room, etc.
Sticking the manipulation wheels out
1) Drive the chair up from its lowest position (c. 10 cm).
2) Push on the button for sticking the wheels out.
3) Hold the button for sticking wheels out and simultaneously drive the chair to
the lowest position, which inclines the base and sticks the wheels out.
4) The button does not need to be held – it is pressed permanently (it holds
itself)
5) Now take hold of the chair by holding ends of footrests, lift them and then
you can manipulate with the chair.
