Positioning
The screen can be tilted horizontally by 0
o
to 15
o
. Height adjustment of the
screen is not possible. The arm with the screen moves along with the chassis of
the gynaecological chair.
The screen can be tilted on the joint in the arm in the range from – 55
o
to + 55
o
.
15
o
0
o
