32
11.1.1 Central STOP Button
The central STOP button 12 immediately interrupts all bed movements in case of unauthorized bed positioning or
an electronic failure.
Pressing central STOP button 12 immediately stops all bed movements.
11.1.2 Activating GO Button
The GO button 13 activates the keypad or the touchscreens of all control elements.
A GO button is included on a number of different control elements. The function of the GO button is identical on all
control elements.
After pressing the GO button 13, the keypad will remain active for 3 minutes.
During this time the following is possible:
Adjust individual mattress platform elements by pressing the corresponding function buttons.
Disable individual functions with the lock buttons.
Pressing a function button will keep the keypad active for another 3 minutes.
11.1.3 Function Buttons
The function buttons 1, 2, 3, 5 and 6 adjust the position of the backrest, thigh rest and calf rest as well as the til-
ting and extending of the mattress platform. The buttons 9 and 10 allow adjusting the CPR and Cardiac Chair
memory functions.
NOTE Bed positioning which depends on columns is continuous.
NOTE During continuous positioning Backrest stops automatically in 30 and 45 degrees. To continue in
positioning press corresponding button once more.
NOTE Pressing two function buttons at the same time will be recognized as an error by the controller. The
controller will interrupt immediately all bed movements immediately.
To set a position:
Activate the keypad by pressing the GO button.
Press and hold respective button until desired position is reached.
11.1.4 Mains power LED
disconnected from the mains
