LINET Multicare LE User Manual

59
The fault indicator flashing briefly and the battery indicator shows the fault state. Some defects are cleared automatically
(e.g.: drive overheating).
Error
LED1
LED2
LED3
LED4
Drive overheated*
Off
Off
Off
On
Electronics overheated*
Off
Off
On
Off
Brake error
Off
Off
On
On
Retraction not completed
Off
On
Off
Off
5V off limits
Off
On
Off
On
FETclosingpenetrated
Off
On
On
Off
Control circuit overheated
Off
On
On
On
Controlcircuiterror
On
Off
Off
Off
Activation button stuck
On
Off
Off
On
Retraction button stuck
On
Off
On
Off
Activebuttonafterstart
On
Off
On
On
* An acoustic signal occurs before the drive is blocked (short acoustic signalization)
NOTE LED indicators are numbered from theleft (see Fig.)
18.7 Light Indicators
Indicator
Meaning
Go Indicator
 Constantly lit
 Flashing
Hand is on touch sensor; drive wheel is ready for use.
Hand is not on touch sensor; i-Drive is not ready for use.
Fault Indicator
 Constantly lit
 Flashing
i-Drive cannot be activated (i-Drive wheel is not lowered, castor
control lever is braked, bed is connected to the mains).
System is faulty (indicated on battery status indicator, see service manual)
-or-
i-Drive control box heat protection is activated
18.8 Technical Specifications
Specification
Value
i-Drive wheel diameter
8,27 in.
Max. fast forward speed (flat ground, loaded)
4,43 Km/h (±15%)
Max. forward speed (flat ground, loaded)
2,16 Km/h (±15%)
Max. reverse speed (flat ground, loaded)
2,16 Km/h (±15%)
Max. angle of ascent
6°
Noise level (when retracting the drive wheel)
65 dB
